Introducing the new CTX CounterTop XRF spectrometer. The portable Counter Top XRF (CTX) is small, light-weight, safety-interlocked, and battery operated. At less than 7 kilograms in weight, the self-contained CTX is truly portable, and has a small footprint of 14 cm in width.
Contact our team to learn more about the new CTX!
EnquiryThe CTX is all about high performance EDXRF in a small, lightweight and sleek, portable configuration. The durable stainless steel body withstands all environmental conditions and is easy to clean. At under 7.5 kg and less than 27 cm high, the CTX is truly portable and takes up very little space on any surface. The CTX fits securely into its standard Pelican case and optional protective backpack. All user operation is through a front panel touchscreen display or an optional PC via USB. Connections are within easy reach under the display. Samples can be placed as-is inside a safety chamber with ample room or in sample cups, baggies or other containers.
The CTX uses a 4W X-ray source featuring Bruker's patented SharpBeam™ optimized X-ray geometry, a high-performance silicon drift detector (SDD) with Bruker’s patented DetectorShield™, as well as Bluetooth® and USB connectivity. The CTX’s touchscreen user-interface provides measurement control and results display. Additionally, Bruker’s Toolbox PC software enables full remote operation of the CTX and optional PC software includes Bruker’s Artax™ for advanced qualitative, semi-quantitative composition analysis, as well as EasyCal™ for user-defined empirical correlations.
The CTX is available in several configurations optimized for different industries and applications, such as:
The CTX is specifically designed for applications which require sample preparation and/or sample presentation in a cup or bag, as well as for small samples and samples which require measurement times of more than a few seconds. Please contact our scientists to discuss your application.
While the CTX was primarily designed for deployment in mobile and field labs, it is also well suited to central labs and on the factory floor for quick pre-screening or routine analysis, and as a back-up for larger XRF or ICP/AA systems.
Calibration range (depending on specific calibration):
Weight: 7.1 kg (15.6 lbs) with battery
Size: 13.5 cm x 25 cm x 35 cm (5.3 in x 9.8 in x 13.8 in) W x D x H
TITAN Detector Shield(TM):
Detector:
Collimator options:
X-ray tube: Rh target; max voltage 50 kV
Filter changer:
Languages Supported: Chinese, Chinese simplified, Dutch, English, French, French Canadian, German, Indonesian, Italian, Japanese, Korean, Polish, PortugueseBR, Russian, SpanishMEX, SpanishSPN, Thai, Turkish
Bruker’s CTX CounterTop XRF is capable of doing the same applications as the handheld S1 TITAN. In fact, all calibrations available for the S1 TITAN are also available for the CTX. The biggest difference between the CTX and the S1 TITAN are as follows:
